Leadshine CS-D403 - Technical Specifications; Electrical and Environmental Specifications

CS-D403 Closed Loop Stepper Drive User Manual
Page | 2
2. Specifications
2.1 Electrical Specifications
Parameters
Min
Typical
Max
Unit
Output Current
0.5
-
3.0 (Peak)
A
Operating Voltage
20
24
50
VDC
Logic signal current
7
10
16
mA
Pulse input frequency
0
-
200
kHz
Minimal pulse width
2.5
-
-
μS
Minimal direction setup
5.0
-
-
μS
Isolation resistance
500
MΩ
2.2 Environment
Cooling
Natural Cooling or Forced Cooling
Operating Environment
Environment
Avoid dust, oil fog and corrosive gases
Ambient Temperature
0°C － 65°C (32°F - 149°F)
Humidity
40%RH－90%RH
Operating Temperature
0°C － 50°C (32°F - 122°F)
Vibration
10-50Hz / 0.15mm
Storage Temperature
-20°C － 65°C (-4°F - 149°F)
Weight
Approx. 280 g (9.9 Oz)
