Appendix A. Leadshine CS-D508 Compatible Stepper Motors
The following Leadshine stepper motors with 1000-line encoders have been tested working with the CS-D508 closed
loop stepper drive.
Model
Frame Size
(NEMA)
Torque
(N.m / Oz-In)
Series
Length
(mm / inch)
Notes
CS-M21702
17
0.2 / 28
CS-M
56/2.20
-
CS-M21704
0.4 / 57
63/2.48
-
CS-M21706
0.6 / 85
70/2.76
-
CS-M21708
0.8 / 113
83/3.27
-
Note: all above stepper motors are mounted with 1000-line incremental encoders, contact with Leadshine for stepper
motors with 2000-line, 2500-line, 5000-line encoders.
