Front view (cont.'d)
LED
There are two LED indicators on the front panel. Their definitons are
described below.
STATUS Green OFF Power is off.
Blink Power is on but there are some
problems. The detail will be displayed
on the display (LCD or external
display).
ON Power is on and the videophone is
running well.
VIDEO/MSG Yellow OFF No video transmission.
ON Video is being transmitted.
Blink There is unread message(s).
Name Color Description
XTP8886 User's Manual 9
