After selected items and press [ENTER], the screen will display the
interface as shown below:
Press [ESC] to return to Diagnostic Menu.
Select [View Graphic Items] in Data stream menu and press [ENTER], the
screen will display the interface as shown below:
con.
Sel ect Datastream
[ ]
Engine coolant temperature
[ ]
Calculated LOAD value
[ ]
Short term fuel trim - bank 1
[ ]
Long term fuel trim - bank 1
[ ]
Intake air temperature
1/1
con.
All Datastream
1/8
con.
Sel ect Datastream
[ ]
Fuel system 1 status
[ √ ]
Fuel system 2 status
[ √ ]
Calculated LOAD value
[ √]
Engine coolant temperature
[ √]
Short term fuel trim - bank 4
1/1
Fuel system 1 status N/A
Fuel system 2 status N/A
Calculated LOAD value 2.0%
Engine coolant temperature -35 C
Short term fuel trim - bank 4 -36.1%
To Next Page
