Operation Manual Page 10 of 27
Fitting Instruction for R12
Step 1: Guide the hook from the crane into the shackle
(2) and slide onto the fitted quick-assembly plate from
the side
Step 2: Bolt the machine securely in place with the
hexagon bolt (1)
