Operation Manual Page 22 of 27
Simultaneous cutting and beveling
Pipes with less than 4.5 mm wall thickness can be cut
and beveled simultaneously.
Important Notice: If using an additional cutter, turn the
motor slower around the pipe than normal cutting.
Important Notice: Lubricate the saw blade and
additional cutter during work. For non-stop operation,
non-stop operation, after cutting, loosen the hexagon
nut no top of saw blade to avoid damage caused by
tension.
Hard plastic cutting process
For hard plastic pipe with wall thickness less than
2.5 mm
Follow the cutting procedures until Step 7
Step 7: Slowly turn the motor using the lower grip
handle (1) and top handle wheel (2) Counter Clockwise
until the wall of the pipe/tube has been cut off.
Step 8: Switch off the motor
