Operation Manual Page 12 of 27
Step 3: Clean the saw blade shaft and vicinity
Step 4: Fit the saw blade (2) or bevel cutter and the
clamping plate (3)
Step 5: Tighten the hexagon nut (4).
Step 6: Move the saw blade guard (1) back to its original
position.
Install additional cutters
Step 1
: Turn the saw blade guard (1) down for approx.
90°.
Step 2: Loosen the hexagon nut (5). Remove the
clamping plate and the saw blade.
