Operation Manual Page 9 of 27
Transportation and Fitting of the machine
Danger of death or injury caused by electric shock
• Disconnect power before transporting, mounting
or dismounting.
• Transport and fit the machine with the aid of
crane or similar lifting device
Fitting Instruction for R2, R4, R6 and R8
Step 1: Clamp a suitable pipe of sufficient length
centrically in the vice
Step 2: Position transport belts around the pipe on both
sides
Step 3: Raise the machine on the belts and guide it
sideways onto the fitted quick-assembly plate
Step 4: Bolt the machine securely in place with the
hexagon bolt (1).
