Lefon R4 - Slide Guide Cleaning

________________________________________________________________________________________________
_______________________________________________________________________________________________
Operation Manual Page 26 of 27
Slide guide cleaning
Step 1
: Clamp in a suitable pipe
Step 2
: Remove the cover plate (3) using the hexagon
Allen Key.
Step 3: Rotate the slide (2) all the way down using the
top handle wheel (1)
Step 4: Pull the slide (2) out towards the front
Step 5
: Clean the guide of the slide housing and slide.
Lubricate both parts with HD 30 engine oil.
Step 6: Reassemble the pipe cutter
