Diagram 14
Connections with RJ45 – Cat 5E/6 cable.
4 Wires
2 Wires
F F I I #I #I
0 1 0 1
1# 2# 3 # 4#
B DCA
+
– –
+
321070
323023
323010
CF1= OFF
CF2= OFF
CF3= OFF
CF4= ON
322020 322020
323015 323015
single family system witH more tHen 1 entry panel
106
WIRING DIAGRAMS - VARIANTS
