128
321010Colour 5.6” handsfree indoor handset
Connection way for NC and NO contacts
PIN ALARM AREA SENSOR TYPE SENSOR TYPE
REMARK
F1 SENSOR 1
THEFT ALARM
INFRARED SENSOR
Can use short key to sensor active or idle
F2 SENSOR 2 DOOR SENSOR
F3 SENSOR 3
FIRE ALARM
SMOKE SENSOR
Can’t use short key to let sensor idle
F4 SENSOR 4 GAS SENSOR
F5 SENSOR 5
THEFT ALARM
Infrared or non-infrared;
Default is infrared sensor;
User can set it to be non infrared
Can use short key to sensor active or idle
F6 SENSOR 6
Infrared or non-infrared;
Default is non-infrared sensor;
User can set it to be non infrared
F7 SENSOR 7
Infrared or non-infrared;
Default is infrared sensor;
User can set it to be non infrared
F8 SENSOR 8
Infrared or non-infrared;
Default is non-infrared sensor;
User can set it to be non infrared
GND
+ 12 V
BT00468-b-EN 15/05/2013
