System composition
Apartment 1
Apartment 2
Apartment 4
Apartment 3
To floor
shunt 323003
Entrance panel
Floor shunt 323002
Power supply 323005
Riser 1
BRANCH 1 FLOOR 1
For the installation of video systems
with several branches, the 2-way video
SINGLE BUILDING WITH MORE RISERS
2-Way Video
Splitter 323007
splitter, 323007, and the floor shunts,
323002, can be used.
