LEGRAND D45 SYSTEM User Manual

GENERAL RULES FOR INSTALLATION
caBles used
cat. 5e u/utp caBleS
032750
Category 5E U/UTP unshielded cable with 24AWG (0.51 mm) solid copper conductors, polyolen insulation,
4 pairs of twisted conductors with internal separator - in accordance with ISO/IEC 11801,
and 2.0, EN 50173-1 and EIA/TIA 568 B2.10 standards - grey colour.
U/UTP Sheath Length Packaging
032750 LSZH 305 m box
032751 PVC 305 m box
032873 LSZH 1000 m reel
032874 PVC 1000 m reel
cat. 6 u/utp caBleS
032754
Category 6 U/UTP unshielded cable with 24AWG (0.51 mm) solid copper conductors, polyolen insulation,
4 pairs of twisted conductors with internal separator - in accordance with ISO/IEC 11801,
and 2.0, EN 50173-1 and EIA/TIA 568 B2.10 standards - blue colour.
U/UTP Sheath Length Packagings
032754 LSZH 305 m reel
032871 LSZH 1000 m reel
032872 PVC 1000 m reel
System cable
32
