27
KEOR T
Operating Manual
6.2. Internal SNMP Communication
Internal SNMP card can be installed into SNMP slot placed at the front of UPS. As soon as SNMP installed,
RS232 port would be disabled.
Internal SNMP has the same features as External SNMP; refer to Section 6.1 for more information.
NMP JUMPER (J2 – J3): If internal SNMP would be used, 2 jumpers should be moved to upper side.
If RS232 or RS485 would be used, 2 jumpers should be moved to lower side.
SNMP RS232 - RS485
If the jumpers are at the upper side for internal SNMP conguration, RS232 and
RS485 Serial Communication are disabled.
If the jumpers are at the lower side for RS232 or RS485 conguration, internal
SNMP is disabled.
To Next Page
