LEGRAND VANTAGE CC-STAT - Page 21

21
No: IS-0685 – Rev. 2
System Setting Description Factory Default Setting (Bold)
and Setting Range
40. LOCKOUT TYPE Screen lockout level (Override lockout by
holding [MENU] for 7 seconds
OFF
PARTIAL
FULL
41. MODE LOCKOUT System mode lockout setting DISABLE
ENABLE
42. FAN LOCKOUT Fan Mode lockout setting OFF
TIMED
FULL
43. SETPOINT LOCKOUT TYPE Setpoint lockout setting OFF
TIME-LIMITED
RANGE-LIMITED
TIME AND RANGE
FULL
44. MAX SETPOINT CHANGE IN
LOCKOUT
Select setpoint limits (only available when
lockout is set to partial lockout)
+/- 5 DEGREES (from current setpoint)
±1° to 20° OFF indicates no setpoint
changes
-or-
+/-5% RH (from current setpoint)
±% to 20% OFF indicates no setpoint
changes
45. TEMPORARY CHANGE
PERIOD
Time-limited lockout temporary change period 60 MINUTES
Select 0 to 255 minutes in 5 minute step;
0 indicates no temporary change period
46. NETWORK OVERRIDE Network override feature setting ENABLE
DISABLE
47. DISPLAY REMOTE
SENSORS
Enable or disable display of support module
monitor (remote) sensor readings
ENABLE
DISABLE
48. AIR FILTER ALARM PERIOD The period for displaying the “Change Air
Filter” message
OFF
1, 3, 6, 12 MONTHS or “OFF” to disable
49. WATER PANEL ALARM
PERIOD
Set number of months until the rst reminder
is required. The following reminders will occur
every 12 months for a ow through himidier,
and 3/9 months for a drainless humidier
OFF
1 to 12 MONTHS or “OFF” to disabl
50. HUMIDIFIER TYPE Select humidier type. Flow through type gives
a 12 month reminder, and drainless gives a
3/9 month reminder
FLOW THROUGH (1 reminder per
season)
DRAINLESS (2 reminders per season)
51. DEHUMIDIFIER ALARM
PERIOD
The period for displaying the “Service
Dehumidier” message
OFF
1 to 12 MONTHS or “OFF” to disable
52. HVAC ALARM PERIOD The period for displaying the “Service HVAC”
message
OFF
1 to 12 MONTHS or “OFF” to disable
INSTALLER SYSTEM SETTINGS TABLE (continued)
