No: IS-0685 – Rev. 2
System Setting Description Factory Default Setting (Bold)
and Setting Range
00. Network Address Network communication address 1
Address selection of 1 to 64 in steps of 1
01. NUMBER OF NODES Total number of thermostats on the network 64
Selection of 1 to 64 in steps of 1
02. BAUD RATE Communication baud rate 9600
19200
03. CONTROLLER TYPE Sets controller to Thermostat or Humidistat THERMOSTAT
HUMIDISTAT
04. EQUIPMENT TYPE Equipment type is set by SW1 HEAT/COOL
HEAT PUMP
05. CONTROL SETUP Used to lockout heating or cooling outputs
(only available in Heat/Cool mode)
HEAT/COOL
HEAT ONLY
COOL ONLY
06. AUTO CHANGEOVER Enable or disable Auto changeover mode DISABLE
ENABLE
07. NUMBER OF STAGES Number of stages of equipment SINGLE
MULTI
08. AUX HEAT STAGES Number of stages of auxiliary heat equipment ONE
TWO
09. Heat/Cool: FAN CONTROL
IN HEATING
Heat Pump: AUXILIARY
EQUIPMENT TYPE
Heat/Cool: Determines if the thermostat or
equipment controls the efan in heating.
Heat Pump: Auxiliary Equipment type.
1
GAS / OIL HEAT (equipment controls fan)
ELECTRIC HEAT (thermostat controls fan)
10. Thermostat:
COMPRESSOR MIN OFF TIME
Humidistat: HUMIDIFIER MIN
ON/OFF TIME
Thermostat: Minimum off time for
compressor protection
Humidistat: Minimum on/off time for
dehumidier protection
5 MINUTES
1 to 5 MINUTES
11. Thermostat: HEATING MIN
OFF TIME
Humidistat: HUMIDIFIER MIN
ON/OFF TIME
Thermostat: Minimum off time for heating
Humidistat: Minimum on/off time for
humidier
2 MINUTES
1 to 5 MINUTES
12. EQUIPMENT MIN ON TIME Minimum on time for heating and cooling 2 MINUTES
1 to 5 MINUTES
13. AUTO CHANGEOVER TIME Minimum time between heating and cooling
calls
4 MINUTES
1 to 5 MINUTES
14. REMOTE SENSOR Select if remote sensor is attached at T1 and
T2
NO
YES
15. OUTDOOR SENSOR Select if remote sensor is attached at T1 and
T2
NO
YES
16. CONTROL SENSOR
BACKUP
Control sensor failure response STOP CONTROL (enter Error Mode)
USE BUILT-IN
17. FIRST STAGE
DIFFERENTIAL
1st Stage differential 1°F (0.5°C)
1°F to 9°F (0.5C to 4.5°C)
18. SECOND STAGE
DIFFERENTIAL
2nd Stage differential 1°F (0.5°C)
1°F to 9°F (0.5C to 4.5°C)
INSTALLER SYSTEM SETTINGS TABLE
The following table is the list of the settings and their details. Default settings are shown in bold. Some settings are only available to
thermostats set to heat pump or humidistat mode.
1
If utilizing a fossil fuel auxiliary heat system, set to Gas or Oil Furnace. In this setting, the heat pump will lock out before the fossil
fuel auxiliary heat comes on; eliminating the need for a dual fuel kit. If utilizing electric auxiliary heat, set to Electric. In this setting, the
heat pump and electric auxiliary heat are allowed to run simultaneously.
