The grid corner points
can be adjusted by
touching or clicking on
it and moving it to the
desired location. Then
relock it.
6.4 Mapping Utilities Using a Positioning System
The DSX can be combined with several different types of positioning systems
to greatly improve the mapping capabilities of the DSX. The DSX supports
numerous different types of GNSS antennas that provide various levels of GPS
accuracy. Refer to 6.4.1 GNSS Antennas.
In addition, the DSX can also be paired with Total Positioning Systems (TPS) to
directly stream the coordinates of the DSX to DXplore. Refer to 6.4.2 TPS Sys-
tems.
The GNSS connection can be done:
•
Via DXplore direction connection (full integration for the antenna)
•
Via DXplore NMEA connection (antennas that do not support DXplore
direct connection)
The table explains the DXplore support for a list of antennas, also highlighting
the connection type recommended for each antenna model.
Antenna
model
DXplore direct connection DXplore NMEA connection
RTK via tab-
let Internet
connection
RTK via
antenna SIM
card Inter-
net connec-
tion
RTK via tab-
let Internet
connection
RTK via
antenna SIM
card Inter-
net connec-
tion
Leica GS18 T (Option in
DXplore UI)
(Option in
DXplore UI)
(Setup from
controller
software UI)
(Setup from
controller
software UI)
Leica GS16 (Option in
DXplore UI)
(Option in
DXplore UI)
(Setup from
controller
software UI)
(Setup from
controller
software UI)
Leica
GG04 plus
(Default) - (Default) -
Leica FLX100 (Default) - (Default) -
iCON iCG70T (Default) - (Default) -
iCON iCG60 - - (Setup from
antenna
panel/
controller
software UI)
(Setup from
antenna
panel/
controller
software UI)
Geomax
Zenith40
(Option in
DXplore UI)
(Option in
DXplore UI)
(Setup from
controller
software UI)
(Setup from
controller
software UI)
Overview
56 Procedures for Working with the DSX
