56
Version 2.0, Revision I
Cleaning and Maintenance
6
Fig. 46
• Transport station (→ "Fig. 46")
Remove dust and debris from the specimen
slide carrier.
Fig. 47
1
Fig. 48
• Slide dispense chute (→ "Fig. 48")
The swivelling flap must be open
(→ "Fig. 47-1")
The chute must be clean (→ "Fig. 48").
Caution
Sensitive electronics components
are located in this area.
Use no liquid in this area!
• Close the flap after cleaning and before
using the instrument.
