Transformers
Follow the safety instructions given on page 7.
Leica transformers may only be opened by authorized service
personne l, and the power cable must be disconnected before-
hand. The transformers are not to be used outdoors.
Regulating transformer
The regu l ating transformer 0-7 V/40 VA is used to operate the
6
V/10 Wand 6 V/20 W lamps.
1 Voltage selector
2 Connections for two lamps {maximum comb i ned
loading 40 W)
3 Connection for power cable
4 Fuse holder F1.0 A
5 Power switch
I on
0 off
6
ON display: Instrument is switched on.
7 Regulating knob
8 6 V display: The maximum voltage has been reached.
~Set the available voltage
on the voltage se l ector.
-Position 115for 100 - 120 V
- Position
230 for 200-240 V
11>- Connect the power cable to the socket of the base and to
the power source.
11>- Conne ct the l amp . The sockets accept two lamps with
a
maximum comb i ned loading of 40 W.
Leica M Stereomicroscopes -I ll um i nat i ons
Switching
on and off
You can prolong the life of your bulb if you :
~ First switch off the lamp by turning the
rotary knob into the black range
~ and only then switch the transformer
on or off.
~Turn on the power switch.
The diode is il l uminated.
~ Use the rotary knob to adjust t he
brightness.
Above 6 V the diode is illumi nated.
Changing fuses Fuses 1.0A, 5x 20 {stock no. 167 651)
~ Lamp off.
~ Power switch off.
~Turn the fuse holder counterclockwise
and extract it.
~ Fit a new fuse and replace the fuse
holder.
In the event of ~ Lamp off.
overload ~ Power switch off.
~Wait a few seconds.
~ Power switch on.
~Lamp on .
Step transformer
Follow the safety instructions given on page 7.
• You can attach a 6 V/1 0 W l amp to the step transformer.
~Set the voltage selector on the r ea r
side
to 115 V or 230 V.
~Attach the power cable to the power
supply.
~Con n e c t the lamp.
~Adjust the bright ness with the three-
st
ep switch {4/5/6 V).
