UNITY MOTORHOME MOTORHOME OPERATION
11� Peel back the exterior sweep gasket
13
from the
top corners of the slide out, and lift the slide out
motor about 1/2'' to release.
13
12� Push in the slide out room until fully retracted,
keeping both sides of the slide out level with the
coach while retracing�
NOTE: Manual movement of the slide out
requires signicant effort and may require the
assistance of several people.
13� Peel back the exterior sweep gasket
13
from the
top corners of the slide out, and reengage the
slide out motor�
14� Replace the motor mounting screw
11
on each
side of the slide out, and replace the microwave.
15� Reconnect both electrical connectors (
5
&
6
) to
the control module
4
�
16� Install the travel lock before moving the
motorhome�
ACCESSING THE MOTOR WHEN SLIDE OUT IS
OUT
1� Turn the battery disconnect switch to the “OFF”
position, and disconnect the shore power. Refer
to the "Battery Disconnect Switch" section in the
“Electrical System Operation” section.
2� Locate the control module
4
(installed in lower
galley.)
4
5
6
3� Unplug both motor electrical connectors (
5
&
6
)
from the control module
4
�
If you have unplugged the motor electrical
connectors (
5
&
6
) from the control
module
4
, do NOT move the motorhome
unless the slide out room and the slide
out room motors electrical connectors
(
5
&
6
) are reconnected to the control
module
4
. Reconnecting the motor electrical
connectors to the control module applies a
brake to the slide out room motors, keeping
the slide out room locked in position.
CAUTION
4� Remove the slide out snap-on trim boards
12
on both sides�
