UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION
ADJUSTING THE TENSION
INCREASING TENSION
To increase the spring tension remove the end cap,
and use a at head screw driver to twist the tension
adjustment screw
1
on the left side of the shade
clockwise until the preferred tension is reached. If
there are two shades in the Impulse Platform, you
must modify the tension individually.
11
DECREASING TENSION
To decrease the spring tension remove the end
cap, and use a at head screw driver to twist the
tension adjustment screw
11
on the left side of the
shade counterclockwise until the preferred tension
is reached� If there are two shades in the Impulse
Platform, you must modify the tension individually.
CLOSING THE ROOF VENT
1� Lift the handle
6
to release it from the seat
7
�
2� Pull down the roof vent down using the handle
6
�
3� Ensure latch
5
securely locks the handle
6
in
the closed position�
ADJUSTMENTS FOR DAY/
NIGHT SHADES
The spring tension should be accurately set in order
to rewind the material gradually back into the fully
rolled up position. Too much tension in the spring
may cause damage to the shade material�
REMOVING END CAP
1� Reach with your hand between the end cap
8
and the wall as shown in gure
9
�
8
9
2� Push clip
10
away from the wall with your hands
still in the same position as gure
9
�
10
3� Pull off end cap
8
�
