60
APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME
MANUAL ROOF VENT
Use the manually operated roof vent
3
in conjun c t i o n
with the power roof vent to provide adequate air ow
throughout the motorhome�
The roof vent is equipped with a blind
4
that slides
across the opening to limit the amount of sunlight
entering the motorhome�
4
4
3
When leaving the motorhome for extended
periods, ensure all roof vents are fully closed
to prevent rain from entering the coach interior.
NOTICE
OPENING THE ROOF VENT
1� Press the latch release button
5
on the handle
6
�
2� Push upwards on the handle
6
and latch the
handle bar into the desired seat
7
�
5
6
7
SIDE WINDOW VENTS
Turn the knob
1
counterclockwise to open the
window vent and clockwise to close the window vent.
1
To open egress windows (if equipped), pull up the
two handles
2
, and push out the window.
2
2
