UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION
INTERIOR LIGHTING
CEILING AND OVERHEAD CABINET LIGHTS
1
1
2
NOTE: This is a sealed LED unit and must be
replaced as complete unit�
1� Pull down on the light tting
2
�
2� Install a new light into the opening�
LED lights are not serviceable. If any light
stops working, have the entire light replaced
by a qualied service technician.
NOTICE
NOTICE
UNDER CABINET LIGHTS
3
Under cabinet lights are not serviceable. If the under
cabinet light stops working, have the entire unit
replaced by a qualied service technician.
3
3� Unclip the electrical connector
8
from the light
you are replacing�
8
9
9
10
11
4� Remove the two nuts
9
securing the support
bracket
10
to the light assembly and remove the
support bracket.
5� Remove the defective light
11
and install a new
one�
NOTE: The lights
11
are sealed with a bead
of silicone to prevent dust and moisture from
entering the light assembly
7
. Carefully remove
the silicone when changing the light and apply a
new bead before reinstalling the light assembly�
6� Reinstall the light assembly
7
by following Step
5 to Step 1 in reverse order.
EXTERIOR LIGHT
8
8
9
1� Unclip plastic cover
9
�
2� Remove and replace light.
3� Install cover.
