Page 31/95
21January2021/Version 0
LEM International SA
Chemin des Aulx 8
1228 PLAN-LES-OUATES Switzerland
www.lem.com
i
To connect and disconnect the wires, use a screwdriver 3 x 0.5 mm (DIN 5264)
For detailed explanation of this graph, please refer to the below table "Table 1: Ports denition"
and gure "Figure 16: Connection and wiring diagrams".
A
B
C
8 mm
0,13 ... 1,5 mm²
0.31 in.
24 ... 16 AWG
Click!
Click!
Click!
10 ... 11 mm
0.39 ... 0.43 in.
0,25 ... 1,5 mm²
23 ... 16 AWG
0.6 N.m max.
Figure 15: DCBM connection
A
Ethernet cable
Data Link cable
Bus bars or lugs
