Statuserrors 

The DCBM provides status and error ags allowing monitoring of its proper installation, its
readiness towards transactions, the fulllness of its logbook, its internal operation, among others.
Those ags are available under various formats as follows:
• In /status API: current status and errors
• In /legal API: transaction status
• In /ocmf API: OCMF EF and ST elds
Additionally, /logbook API keeps track of raised statuses when a new event occurs.
Refer to "7.6. Event logbook".
value
In /status API, status and error ags are available through two formats, as follows. In /legal
API (see §7.1), only value eld format is used.
“suLinkStatusIsOk”
“status”: {
“value”: 17,
“bits”: {
: true,
“muFatalErrorOccured”: false,
“transactionIsOnGoing”: false,
“tamperingIsDetected”: false,
“timeSyncStatusIsOk”: true,
“overTemperatureIsDetected”: false,
“reversedVoltage”: false,
“suMeasureFailureOccurred”: false
}
},
Format 1: value
Concatenation of flags as a
binary value
Format 2: bits
List of flags with explicit
name and unitary value
“errors”: {
“value”: 0,
“bits”: {
“muInitIsFailed”: false,
“suStateIsInvalid”: false,
“versionCheckIsFailed”: false,
“muRngInitIsFailed”: false,
“muDataIntegrityIsFailed”: false,
“muFwIntegrityIsFailed”: false,
“suIntegrityIsFailed”: false,
“logbookIntegrityIsFailed”
: false,
“logbookIsFull”: false,
“memoryAccessIsFailed”: false,
“muStateIsFailed”: false
}
},
Figure 44: Description of the 2 formats of status and errors
