13
Unused
wires
Single wire
to terminal “C”.
Indoor Unit Controller
PureAir
S
Figure 12. Communicating Indoor Unit and PureAir
S
Wire Jumper required between ON and RED terminals.
ACC1 is always low-stage for single- and two-stage
ventilators.
LO
W
ON
RED
YE
L
GRN
HI
CO
M
NO
NC
BLK
HRV/ER
V
Te
rminal Block
CO
M
CL
OSE
Fresh
Air Damper
2-Wire Control
(Normally Open)
ACC1
ACC2
MAG-MOUNT
SMART HUB
ACC1
ACC2
MAG-MOUNT
SMART HUB
Wire jumper required between
ACC 1 and R terminals.
-
COMMBUS
A
B
+
-
COMMBUS
A
B
+
Figure 13. iComfort S30 with V
entilation
(Fresh
Air Damper
, ERV and HR
V)
12
14
Table of Contents
Table of Contents
2
Shipping and Packing List
3
Operating and Storage Environment, Electrical and Dimensions
3
Smart Hub External Component Locations, Button, Leds, Terminals, Wiring Specifications and Sensor Wiring
3
External Component Locations
3
Push Button Functions
4
LED Indicators
4
Terminals and Wiring Recommendations
5
Sensor Wiring
6
HD Display External Components
6
Reducing Electrical Noise
7
Application Wiring
7
Installation Recommendations
14
Smart Hub Installation
14
HD Display Installation
15
Installation
15
Mounting Display to Subbase
16
Lennox Communicating Air Handler Electric Heat Configuration
16
Auto Detection
16
Manual Configuration
16
Commissioning and Service (Using the Mobile Setup Application)
17
Mobile Device Operating System Requirements
17
Establishing a Direct Wireless Connection to the Smart Hub
17
Service
18
Alternative Method
18
Commissioning (Using the HD Display)
19
Apple Homekit Wi-Fi Accessory Configuration
19
Dealer Info
19
General Information
19
Equipment Found Screen
20
Reminders
20
Iharmony Zoning
20
Commissioning Completion
21
Equipment Parameters
23
Tests
42
Diagnostics
42
Installation Report
42
Information
43
Dehumidification Settings
43
Dehumidification Setting Options
43
Overcooling
43
Dehumidification Set Point
43
Advanced Dehumidification Descriptions
44
Displaying Outdoor Temperature (Sensor) and Indoor Humidity on the Home Screen
45
Displaying the Outdoor Sensor Temperature on the Home Screen
45
Displaying the Indoor Humidity on the Home Screen
45
Iharmony Zoning
45
Pureair S
45
Ventilation (ERV, HRV and Fresh Air Damper)
45
Ventilation Rates
45
Energy Recovery Ventilator (ERV)
46
Heat Recovery Ventilator (HRV)
46
Fresh Air Damper
46
Zoning Application
46
Operation of Fresh Air Dampers with Environmental Overrides
46
Wiring
46
Ventilation Control Modes
46
Communicating System Configurations
47
Furnace and Air Conditioner
47
Furnace and HP Unit (Dual-Fuel)
47
Air Handler and Air Conditioner
48
Air Handler and Heat Pump Unit
48
Hybrid System Configurations
49
Communicating Furnace and Conventional Air Conditioner
49
Communicating Furnace and Conventional Heat Pump Unit (Dual Fuel)
49
Communicating Air Handler and Conventional Air Conditioner
50
Communicating Air Handler and Conventional Heat Pump Unit
50
Equipment Interface Module
51
SLP98V Variable Capacity Furnace Default Setting
51
Wi-Fi Connection
51
Performance Reports
53
Mobile Applications
53
Notifications (Service and Alert Codes)
53
Alert Code Types
53
Soft Disable
54
Service Notification Codes
54
Alert Codes
55
Technical Support and Mobile App for Installers/Technicians Only
101
Technical Support for Installers/Technicians Only
101
Icomfort Mobile Setup Application for Installers/Technicians Only
101
Lennoxpros Mobile Application for Installers/Technicians Only
101
Lennoxpros Dealer Dashboard
101
Service Dashboard Search Screen
101
Customer Results Screen
101
Customer Details Screen
101
Index
103
