45
Displaying Outdoor Temperature (Sensor) and Indoor Humidity
on the Home Screen
Displaying the Outdoor Sensor Temperature on the Home Screen
An outdoor temperature sensor is provided in all iComfort outdoor units. To
display the outdoor temperature on the home screen of the HD Display, you
can enable this feature under the dealer control center. Use the following
procedure to enable the outdoor temperature sensor display
1. Touch menu and then touch settings.
2. Touch advanced settings and then touch view dealer control center.
3. Touch equipment and then touch thermostat.
4. Touch Outdoor Temperature and touch sensor.
5. Touch the back arrow (<) at the top left-hand of the screen to return to the
dealer control center.
6. Touch exit.
7. From the Home screen, touch menu and then touch settings.
8. Touch display and touch outdoor temperature.
9. Touch sensor to touch the outdoor sensor. Touch < display to return to
display screen. There under outdoor temperature it will indicate sensor.
10. Touch the home icon at the top left-hand corner of the screen to return to
the home screen.
Displaying the Indoor Humidity on the Home Screen
To enable the Indoor Humidity Display on the Home screen use the following
procedure:
1. Touch menu and then touch settings.
2. Touch advanced settings and then touch view dealer control center.
3. Touch equipment and then touch thermostat.
4. Touch Display Indoor Humidity and touch the toggle switch to turn on.
5. Touch the back arrow (<) at the top left-hand of the screen to return to the
dealer control center.
6. Touch exit to return to the home screen.
iHarmony Zoning
The damper control module is compatible with the following Lennox equipment:
• Lennox communicating variable speed or variable capacity (variable capacity)
indoor and two-stage or variable capacity (modulating) outdoor units.
• Lennox communicating variable speed indoor unit and communicating or
non-communicating (conventional) single-stage outdoor unit (two zones
maximum supported).
• Lennox communicating variable speed indoor unit and communicating or
non-communicating (conventional) two-stage outdoor unit (four zones
maximum supported).
• Parameter settings are listed in “Table 12. Zoning Control Parameters” on
page 40.
• Wiring connections are listed in “Figure 8. iComfort S30, Lennox
Communicating Indoor and Outdoor Units, iHarmony Zoning System
(Damper Control Module) and Zone Sensors” on page 9.
PureAir S
The iComfort S30 Ultra Smart Thermostat will require rmware version 3.4 or
higher to take advantage of all of the PureAir S features.
Features included are:
• 4-wire connection to Lennox communicating indoor unit control
• Using sensors to:
» Automatically detect dirty air lter
» Display air lter life percentage
» Monitor UVA lamp operational state (On or Off).
» Display UVA lamp life percentage
• Parameter settings are listed in “Table 14. PureAir S Parameters” on page
41.
• Applicable alarms for PureAir operations are listed in “Alert Codes” on page
55.
• Wiring connections are listed in “Figure 12. Communicating Indoor Unit and
PureAir S” on page 13.
Ventilation (ERV, HRV and Fresh Air Damper)
This equipment is designed to provide fresh air while exhausting an equal
amount of stale air.
Ventilation Rates
The S30 ventilation function is only a turn on - turn off feature. All CFMs must be
adjusted from the HRV/ERV unit. The ventilation function can be controlled by
outdoor temperatures and by timers in the thermostat. The ventilation feature
can also control 1 and 2 stages of ventilation operation.
