Lennox MHA Series - Heating - 009 (208;230 V); Cooling - 012 (115 V)

18
7.3.4. Heating - 009 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb)
60°F 65°F 70°F 75°F
Total
mBtuh
Total
mBtuh
Total
mBtuh
Total
mBtuh
–13 5.86 5.67 5.37 5.12
–5 6.98 6.75 6.39 6.10
0 8.10 7.84 7.41 7.11
5 8.96 8.69 8.23 7.94
17 10.80 10.48 9.91 9.52
19.4 10.86 10.53 9.96 9.56
24.8 10.94 10.61 10.02 9.67
32 10.98 10.67 10.07 9.56
35 11.10 10.73 10.16 9.60
39.2 11.61 11.23 10.62 10.14
44.6 12.56 12.14 11.47 11.01
47 13.11 12.58 11.96 11.54
53.6 13.55 13.00 12.35 11.86
57 13.82 13.34 12.66 12.03
7.3.5. Cooling - 012 (115V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 9.07 6.41 9.59 6.78 10.06 7.25 10.48 7.55
–5 9.69 6.84 10.26 7.23 10.88 7.92 11.27 8.02
–4 10.01 6.90 10.58 7.29 10.98 7.58 11.50 7.82
0 10.59 7.21 11.08 7.54 11.68 7.95 12.11 8.16
5 10.91 7.54 11.60 8.02 12.04 8.28 12.61 8.70
15 10.99 7.78 11.69 8.28 12.26 8.75 12.77 9.03
25 11.24 7.97 11.76 8.34 12.47 8.88 12.92 9.25
35 11.46 8.04 11.92 8.36 12.51 8.88 13.10 9.25
45 11.36 8.37 12.15 8.95 12.75 9.53 13.21 9.70
55 11.55 8.91 12.14 9.37 12.68 9.60 13.27 10.05
65 11.52 8.14 12.12 8.56 12.71 8.98 13.17 9.31
75 11.53 8.29 12.26 8.82 12.80 9.20 13.40 9.64
85 11.28 8.22 11.80 8.59 12.45 9.07 12.97 9.44
95 10.96 7.69 11.46 8.04 12.09 8.48 12.53 8.78
105 10.08 7.31 10.60 7.69 11.13 8.07 11.65 8.45
110 9.27 7.23 9.81 7.65 10.40 8.11 10.78 8.41
115 8.72 7.41 9.22 7.84 9.57 8.14 10.02 8.52
122 7.98 7.10 8.30 7.39 8.71 7.75 9.12 8.12
