Lennox MHA Series Service Manual

21
7.3.10. Heating - 018 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb)
60°F 65°F 70°F 75°F
Total
mBtuh
Total
mBtuh
Total
mBtuh
Total
mBtuh
–13 6.96 6.69 6.46 6.27
–5 8.30 7.97 7.69 7.38
0 9.23 8.82 8.55 8.25
5 10.25 9.81 9.50 9.21
17 11.92 11.42 11.04 10.54
19.4 12.40 11.90 11.49 10.97
24.8 13.12 12.60 12.15 11.67
32 13.84 13.29 12.80 12.29
35 14.77 14.23 13.70 13.22
39.2 16.28 15.58 15.05 14.45
44.6 18.33 17.54 16.93 16.08
47 19.81 18.88 18.28 17.27
53.6 21.20 20.20 19.54 18.56
57 21.79 20.85 20.12 19.32
7.3.11. Cooling - 024 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 18.76 14.06 19.78 14.81 20.90 15.83 22.47 17.19
–5 20.06 15.12 21.38 16.13 22.59 16.80 24.16 18.14
–4 20.34 14.76 21.94 15.92 23.05 16.73 24.66 18.10
0 21.23 15.30 22.75 16.40 23.64 17.06 25.42 18.33
5 21.53 17.12 23.08 18.36 24.25 19.25 25.94 20.46
15 21.18 17.10 22.98 18.55 24.01 19.29 25.68 20.55
25 21.22 16.54 22.36 17.43 23.63 18.36 25.41 19.45
35 20.90 16.27 22.29 17.35 23.55 18.34 25.18 19.31
45 20.59 15.52 22.21 16.75 23.33 17.59 24.95 18.82
55 20.64 14.98 22.13 16.06 22.99 16.68 24.72 17.94
65 20.33 14.66 21.80 15.72 22.90 16.51 24.49 17.66
75 20.02 15.92 21.72 17.27 22.69 18.04 24.26 19.30
85 20.17 16.28 21.25 17.16 22.46 18.13 24.15 19.50
95 19.95 15.55 21.28 16.58 22.48 17.52 24.04 18.73
105 18.94 14.75 20.43 15.91 21.47 16.71 22.96 17.88
110 18.02 14.67 19.32 15.72 20.18 16.34 21.58 17.33
115 16.75 15.44 17.96 16.56 18.77 17.08 20.18 18.29
122 15.32 14.68 16.62 15.93 17.36 16.64 18.56 17.80
