Step 10. Releasethevehooksintheback.

Hooks

Step 11. Pulloutthepanelframewhilepushingthehook

throughaclearancebetweenthepanelframe

andtheheatexchanger.

Step 12. Releasethe5hooksoftheverticalblades,then

pulltheverticalbladesrightwardandremoveit.

Step 13. Remove1screwofthedisplayboard.

Step 14. Rotatethedisplayboardinthedirectionshownin

therightpicture.

17.1.2. Electrical Parts

NOTE: When handling electrical parts use anti-static

gloves.

NOTE: Remove the front panel (see Step 1 on page 37)

before disassembling electrical parts.

Step 1. Cuttheribbonbyashear,thenpulloutthecoil

temperaturesensor(T2).

Step 2. Removeonexingscrewoftheelectronic

controlboxandtwoscrewsusedfortheground

connection.

Ribbons T2 Sensor

Step 3. Anupwardforceismaintaineduntilthecoverof

electroniccontrolboxisremoved.
