Lenovo 10A2 - Replacing the Secondary Hard Disk Drive

Replacingthesecondaryharddiskdrive
Attention:
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.
Thissectionprovidesinstructionsonhowtoreplacethesecondaryharddiskdrive.
Toreplacethesecondaryharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.
2.Removethecomputercover.See“Removingthecomputercover”onpage36.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage36.
4.Presstheretainingclip1inthedirectionasshownandpivotthedrivebayassemblyupwardatthe
sametime.
Figure81.Pivotingthedrivebayassemblyupward
5.Locatethesecondaryharddiskdrivebay.See“Locatinginternaldrives”onpage17.
6.Disconnectthesignalcableandthepowercablefromtheprimaryharddiskdriveandsecondary
harddiskdrive.
Chapter5.Installingorreplacinghardware79
