Table 30. Removal steps of USB connector board and USB cable assembly (continued)
Cable routing: Route the USB cable assembly as shown in these figures.
For ThinkPad Edge 15″ and E50:
For ThinkPad Edge 14″ and E40:
118 ThinkPad Edge 14″, Edge 15″, E40, and E50 Hardware Maintenance Manual
