1030 Optical drive or travel cover
For access, remove this FRU:
v “1010 Battery pack” on page 78
Table 10. Removal steps of optical drive or travel cover
1
Step Screw (quantity) Color Torque
1 M2 × 8 mm, wafer-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgfcm)
3
2
80 ThinkPad Edge 14″, Edge 15″, E40, and E50 Hardware Maintenance Manual
