1070 Fan assembly
For access, remove these FRUs in order:
v “1010 Battery pack” on page 78
v “1040 Thermal cover” on page 81
Attention:
v Do not handle the fan roughly. Improper handling of the fan can cause distortion
or deformation and imperfect contact with components.
v Do not touch or apply any excessive force to the fan motor. It might cause
damage to the fan assembly or the computer to mulfunction.
Table 14. Removal steps of fan assembly
1
When installing: Make sure that the fan connector is attached firmly to the
system board.
Removing and replacing a FRU 85
