Table 35. Removal steps of hinges, LCD panel, LCD cable, and LCD rear cover
assembly (continued)
5
6
7
3
3
3
3
4
4
Step Screw (quantity) Color Torque
3 M2 × 3 mm, small-head, nylon-coated (4) Black 0.181 Nm
(1.85 kgfcm)
When installing: Make sure that the LCD connector is attached firmly.
Removing and replacing a FRU 129
