In step 2, lift the MG frame a little in the direction shown by the arrow, and then
remove it in the direction shown by arrow 3.
Attention: Before step 2, be sure that the Ultrabay Slim device eject lever is not
popped out and it is housed in its position properly as shown in the figure a.
2
3
a
Removing and replacing a FRU
84 MT 2511, 2512, 2513, and 2514
