In
step
3
,
while
sliding
the
LCD
latch
lever
in
the
direction
shown
by
the
arrow
,
remove
the
bezel
in
the
direction
shown
by
arr
ow
4
.
2
2
2
2
2
2
2
2
3
4
Removing
and
replacing
a
FRU
102
MT
8747,
8749,
9440,
9441,
9442,
9443,
and
9448
Downloaded from LpManual.com Manuals
107
109
Table of Contents
