1060 Keyboard
For access, remove this FRU:
v “1010 Battery pack” on page 56
v “1040 Palm rest or palm rest with fingerprint reader” on page 61
1
Step Icon Screw (quantity) Color Torque
1
M2 × 14 mm, flat-head, nylon-coated
(1)
Black 0.196 Nm
(2.0 kgfcm)
Lift the keyboard a little in the direction shown by arrow 2, and then detach the
connector 3.
2
3
Removing and replacing a FRU
66 MT 8747, 8749, 9440, 9441, 9442, 9443, and 9448
