Rear view
1 Status indicators
Note: For the description of each indicator, see “Status indicators” on page
37.
2 RJ-45 (Ethernet) connector
3 RJ-11 (modem) connector
4 External monitor connector
5 AC power connector
6 Video-out connector
1
2
3
4
5
6
Bottom view
1 Battery pack
2 Battery pack latch
3 Docking connector
4 Hard disk drive cover
5 Stereo headphone jack
6 Microphone jack
7 Wireless radio switch
8 Infrared port
9 3-in-1 Digital Media Reader
4
6
7
5
8
9
1
2
3
Locations
118 MT 8747, 8749, 9440, 9441, 9442, 9443, and 9448
