1050 DIMM
For access, remove these FRUs in order:
v “1010 Battery pack” on page 56
v “1040 Palm rest or palm rest with fingerprint reader” on page 61
2
1
1
When installing: Insert the notched end of the DIMM into the socket. Press the
DIMM firmly, and pivot it until it snaps into the place.
Make sure that it is fixed firmly in the slot and does not move
easily.
Removing and replacing a FRU
ThinkPad Z61t 65
