3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage13.
4Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage21.
5Diagnosticpanel
Thediagnosticpanelvariesbymodel.Fordetailedinformation,see“Diagnosticmodule”onpage23.
6Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive.
Frontviewofservermodelswith123.5-inchharddiskdrivebays
Thefollowingillustrationshowsthefrontviewofservermodelswith123.5-inchharddiskdrivebays.
Figure7.Frontviewofservermodelswith123.5-inchharddiskdrivebays
13.5-inchharddiskdrivearea
6NetworkInterfaceController(NIC)1statusLED
2Rackhandle(left)7NIC2statusLED
3FrontUSBconnectors(2)8SystemerrorLED
4PowerswitchwithpowerstatusLED
9Rackhandle(right)
5Systemidenticationbutton(IDbutton)withIDLED
