7.RemovethescrewthatsecurestheM.2storagedrive.Then,removetheM.2storagedrive.
Figure55.RemovingtheM.2storagedrive
8.IfyouareinstructedtoreturntheoldM.2storagemodule,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage152.
InstallingorremovingtheAnyFabricadapter
TheAnyFabricadapterprovidesexpansionconnectorstoconnectdevices,suchassolid-statedrivesand
otherexpansioncards.YoucanpurchaseanAnyFabricadapterfromLenovo.
ForalistofThinkServeroptions,goto:
http://lenovoquickpick.com/usa/home/thinkserver/rack-and-tower-server
InstallingtheAnyFabricadapter
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage59.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeAnyFabricadapterandfollowthoseinstructionsinaddition
totheinstructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheAnyFabricadapter,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage61.
3.Removetheservercover.See“Removingtheservercover”onpage61.
4.LocatetheAnyFabricadapterconnectoronthesystemboard.See“Systemboardcomponents”
onpage36.
Chapter6.Replacinghardware89
