17.Disconnectallcablesfromthesystemboard.
18.Liftthereleasepin1andtheliftinghandle2todisengagethesystemboardfromthechassis.Then,
movethesystemboardtothefrontoftheserverandcarefullypivotthesystemboardupwardtoremove
itoutofthechassis.
Note:Carefullyhandlethesystemboardbythereleasepin
1andtheliftinghandle2.
Figure130.Removingthesystemboard
19.Placetheoldsystemboardonaclean,flat,andstatic-protectivesurface.Touchthestatic-protective
packagethatcontainsthenewsystemboardtoanyunpaintedsurfaceontheoutsideoftheserver.
Then,takethenewsystemboardoutofthepackage.
Chapter6.Replacinghardware149
