3.Ifyouhaveaslimopticaldrive,installtheslimslim-optical-drivebracketandtheninstalltheslimoptical
drive.See“Removingandreinstallingtheslim-optical-drivebracket”onpage82and“Installingthe
slimopticaldrive”onpage71.
4.Dothefollowingtoconnecttheslimopticaldrive:
a.1:ConnectoneendoftheavailableSATAcabletotheSATA4connectoronthesystemboard.
See“Systemboardcomponents”onpage32.
b.2:ConnecttheotherendoftheSATAcabletotherearoftheslimopticaldrive.
c.3:Connecttheslim-optical-drivepowerconnectorofacomboSAScabletothepowerconnector
attherearoftheslimopticaldrive.
Note:EnsurethattheSATAcableandthepowercablefortheslimopticaldriveareroutedunderthe
powersupplycableandthecomboSASpowercable.
Figure18.Connectingtheslimopticaldrive
5.Routethecablesusingthecabletiesinthechassis.See“Reinstallingtheservercoverandreconnecting
cables”onpage106.
Connectingthe3.5-inchharddiskdrivesandslimopticaldrivewithaRAIDcard
Note:Ifyouareconnectingthe3.5-inchharddiskdriveswithaThinkServer9207-8i6GHBA,theprocedure
issimilar.
Toconnectthe3.5-inchharddiskdrivesandtheslimopticaldrivewithaRAIDcard:
Chapter3.Productoverview27
