6.Ifyouhaveaslimopticaldrive,installtheslim-optical-drivebracket,andtheninstalltheslimoptical
drive.See“Removingandreinstallingtheslim-optical-drivebracket”onpage82and“Installingthe
slimopticaldrive”onpage71.
7.Dothefollowingtoconnecttheslimopticaldrive:
a.1:ConnectoneendoftheavailableSATAcabletotheSATA4connectoronthesystemboard.
See“Systemboardcomponents”onpage32.
b.2:ConnecttheotherendoftheSATAcabletotherearoftheslimopticaldrive.
c.3:Connecttheslim-optical-drivepowerconnectorofthemini-SASto3.5-inchSAScombocableto
thepowerconnectorattherearoftheslimopticaldrive.
Figure21.Connectingtheslimopticaldrive
Note:EnsurethattheSATAcableandthepowercablefortheslimopticaldriveareroutedunderthe
powersupplycableandthemini-SAStoSAScombopowercable.
8.Routethecablesusingthecabletiesinthechassis.See“Reinstallingtheservercoverandreconnecting
cables”onpage106.
Connectingthe3.5-inchharddiskdrivesandslimopticaldrivewithoutaRAIDcard
Toconnectthe3.5-inchharddiskdrivesandslimopticaldrivewithoutaRAIDcard:
Chapter3.Productoverview29
