Chapter4.Locatingparts,controls,andconnectors
Thischapterprovidesinformationtohelpyoulocateyourserverparts,controls,andconnectors.
Machinetype,model,andserialnumberlabel
Thistopichelpsyoulocatethelabelthatcontainsthemachinetype,model,andserialnumberinformation
foryourserver.
WhenyoucontactLenovoforhelp,themachinetype,model,andserialnumberinformationhelpssupport
technicianstoidentifyyourserverandprovidefasterservice.
Thefollowingisasampleofthemachinetype,model,andserialnumberlabel.
Machine Type: XXXX
Model Number: XXX
S/N: XXXXXXX
Figure2.Machinetype,model,andserialnumberlabel
Frontview
Figure3“Frontcontrolandconnectorlocations”onpage12showsthelocationsofthecontrolsand
connectorsonthefrontofyourserver.
