10SATAconnectors1and2(SATA3.0
connectors)
23Rearfanconnector
11SATAconnector3(SATA2.0connector)24Coverpresenceswitchconnector(Intrusionswitchconnector)
12eSATAconnector
25Microprocessor
13Frontfanconnector
26PS/2keyboardandmouseconnector
Internalcomponents
Figure6“Componentlocations”onpage15showsthelocationsofthevariouscomponentsinyourserver.
Toremovetheservercoverandaccesstheinsideoftheserver,see“Removingtheservercover”onpage19
.
Figure6.Componentlocations
1Heatsinkandfanassembly
4PCIcard
2Memorymodule
5Rearfanassembly
3Opticaldrive
6Powersupplyassembly
Chapter4.Locatingparts,controls,andconnectors15
