Lenovo ThinkServer TS130 - Replacing the Front Audio and USB Assembly

•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage50.
ReplacingthefrontaudioandUSBassembly
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage17.
ThissectionprovidesinstructionsonhowtoreplacethefrontaudioandUSBassembly.
ToreplacethefrontaudioandUSBassembly,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage19.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage20.
4.DisconnectthefrontaudioandUSBassemblycablefromthesystemboard.SeeChapter4“Locating
parts,controls,andconnectors”onpage11.
5.NotethefrontaudioandUSBassemblycableroutingandremovethescrewthatsecuresthefrontaudio
andUSBassembly.Then,removethefrontaudioandUSBassemblyfromthechassis.
Figure32.RemovingthefrontaudioandUSBassembly
6.RoutethenewfrontaudioandUSBassemblythroughtheholeinthechassis.
7.PositionthenewfrontaudioandUSBassemblytothechassissothatthescrewholeinthenewfront
audioandUSBassemblyisalignedwiththecorrespondingholeinthechassis.
8.InstallthescrewtosecurethenewfrontaudioandUSBassemblyinplace.
9.ConnectthenewfrontaudioandUSBassemblycablestothesystemboard.SeeChapter4“Locating
parts,controls,andconnectors”onpage11.
10.Reinstallthefrontbezel.See“Removingandreinstallingthefrontbezel”onpage20.
Chapter5.Installing,removing,orreplacinghardware41
