Figure3.Frontcontrolandconnectorlocations
1Opticaldriveeject/closebutton
4Powerswitch
2HarddiskdriveactivityLED
5USBconnectors(2)
3Power-onLED
Rearview
Figure4“Rearconnectorlocations”onpage13showsthelocationsoftheconnectorsontherearof
yourserver.Someconnectorsontherearofyourserverarecolor-codedtohelpyoudeterminewhereto
connectthecablesinyourserver.
