•Ifyouarereplacinganopticaldrive,disconnectthesignalcableandthepowercablefromtherear
oftheopticaldrive,pressthebluereleasebuttonandthenslidetheopticaldriveoutofthefrontof
theserver.
Figure17.Removingtheopticaldrive
5.Slidethenewopticaldrivewiththeopticaldriveretainer1installedintothedrivebayfromthefrontof
theserveruntiltheopticaldrivesnapsintoposition.
Figure18.Installingtheopticaldrive
Chapter5.Installing,removing,orreplacinghardware29
